A Successfull endovascular treatment of femoro-popliteal aneurysm and reliable sonographic control by B-Flow™ at follow-up – a case report
DOI:
https://doi.org/10.59667/sjoranm.v30i2.16Keywords:
endovascular aneurysm repair; peripheral vascular aneurysm; contrast enhanced ultrasound (CEUS); endoleak detection; B-Flow™; ultrasound surveillance;Abstract
Introduction:
Treatment of dilatative arteriopathy, caused either genetically and/ or by classic atherosclerotic risk factors, is still challenging. In contrast to aneurysms of the abdominal aorta, endovascular treatment of femoro-popliteal located aneurysms is rarely performed, mostly because surgical treatment is seen as the only option in most patients. When treated endovascularly, follow-up (FU) control of endoleaks is done by Computed tomography angiography (CTA) or by contrast-enhanced ultrasound (CEUS). Other ultrasound assisted techniques are not used regularly.
Case Report:
77-year-old male patient with dilatative arteriopathy and femoro-popliteal aneurysms (Superficial Femoral Artery (SFA) and Popliteal Artery (PA)) in both legs underwent unsuccessful bypass surgery of the right leg 3 years ago with early re-occlusion and permanent occlusion within months with then chronic critical perfusion and postoperative lymphedema. Patient therefore did not agree to surgical treatment of the left SFA and PA aneurysms. We therefore performed an endovascular repair with two 10x150 mm endoprostheses (Gore Viabahn™). Angiographically a small endoleak after implantation was observed. At the 1st postinterventional FU after 24 h no endoleak neither by CEUS nor by B-Flow™ was detected. Similar results were observed at 3-, 12- and 24-months FU. CTA at 6 months revealed no endoleak and complete patency in the treated vessels in the left leg. The initial Fontaine 2b stadium was improved to a stadium 1. ABI and postinterventional pulse wave oscillography were consequently improved as well. Primary patency of the treated vessel reaches now 24 months.
Discussion:
Although usually treated by open surgery, peripheral aneurysms can be successfully treated endovascularly and easily controlled by ultrasound. Modern ultrasound systems offer alternative ultrasound modi to sufficiently detect or exclude endovascular leakage.
Conclusion:
Endovascular repair of femoro-popliteal aneurysms is a therapeutic option, which should be considered and offered to the patient, when technically possible. It is safe and allows for good results, when endovascular experience is sufficient. Control for endoleaks can adequately and safely be done by B-Flow™ or alternative ultrasound modi with less time and effort than by CEUS.
References
1. Piffaretti, G.; Mariscalco, G.; Tozzi, M.; Rivolta, N.; Annoni, M.; Castelli, P. Twenty-year experience of femoral artery aneurysms. Journal of vascular surgery 2011, 53, 1230–1236, doi:10.1016/j.jvs.2010.10.130.
2. Trickett, J.P.; Scott, R.A.P.; Tilney, H.S. Screening and management of asymptomatic popliteal aneurysms. Journal of Medical Screening 2002, 9, 92–93, doi:10.1136/jms.9.2.92.
3. Dawson, I.; Sie, R.B.; van Bockel, J.H. Atherosclerotic popliteal aneurysm. Br J Surg 1997, 84, 293–299.
4. Cervin, A.; Acosta, S.; Hultgren, R.; Grip, O.; Björck, M.; Falkenberg, M. Results After Open and Endovascular Repair of Popliteal Aneurysm: A Matched Comparison Within a Population Based Cohort. European Journal of Vascular and Endovascular Surgery 2021, 61, 988–997, doi:10.1016/j.ejvs.2021.02.007.
5. Whitehouse, W.M., Jr.; Wakefield, T.W.; Graham, L.M.; Kazmers, A.; Zelenock, G.B.; Cronenwett, J.L.; Dent, T.L.; Lindenauer, S.M.; Stanley, J.C. Limb-threatening potential of arteriosclerotic popliteal artery aneurysms. Surgery 1983, 93, 694–699.
6. Tsilimparis, N.; Dayama, A.; Ricotta, J.J. Open and Endovascular Repair of Popliteal Artery Aneurysms: Tabular Review of the Literature. Annals of Vascular Surgery 2013, 27, 259–265, doi:https://doi.org/10.1016/j.avsg.2012.01.007.
7. Diwan, A.; Sarkar, R.; Stanley, J.C.; Zelenock, G.B.; Wakefield, T.W. Incidence of femoral and popliteal artery aneurysms in patients with abdominal aortic aneurysms. Journal of vascular surgery 2000, 31, 863–869, doi:10.1067/mva.2000.105955.
8. Leake, A.E.; Segal, M.A.; Chaer, R.A.; Eslami, M.H.; Al-Khoury, G.; Makaroun, M.S.; Avgerinos, E.D. Meta-analysis of open and endovascular repair of popliteal artery aneurysms. Journal of vascular surgery 2017, 65, 246–256.e242, doi:https://doi.org/10.1016/j.jvs.2016.09.029.
9. Shahin, Y.; Barakat, H.; Shrivastava, V. Endovascular versus Open Repair of Asymptomatic Popliteal Artery Aneurysms: A Systematic Review and Meta-Analysis. Journal of Vascular and Interventional Radiology 2016, 27, 715–722, doi:10.1016/j.jvir.2016.02.026.
10. Feinstein, S.B.; Coll, B.; Staub, D.; Adam, D.; Schinkel, A.F.L.; ten Cate, F.J.; Thomenius, K. Contrast enhanced ultrasound imaging. Journal of Nuclear Cardiology 2010, 17, 106–115, doi:https://doi.org/10.1007/s12350-009-9165-y.
11. Farber, A.; Angle, N.; Avgerinos, E.; Dubois, L.; Eslami, M.; Geraghty, P.; Haurani, M.; Jim, J.; Ketteler, E.; Pulli, R.; et al. The Society for Vascular Surgery clinical practice guidelines on popliteal artery aneurysms. Journal of vascular surgery 2022, 75, 109S–120S, doi:10.1016/j.jvs.2021.04.040.
12. Serrano Hernando, F.J.; Martínez López, I.; Hernández Mateo, M.M.; Hernando Rydings, M.; Sánchez Hervás, L.; Rial Horcajo, R.; Moñux Ducajú, G.; Martín Conejero, A. Comparison of popliteal artery aneurysm therapies. Journal of vascular surgery 2015, 61, 655–661, doi:https://doi.org/10.1016/j.jvs.2014.10.007.
13. Antonello, M.; Frigatti, P.; Battocchio, P.; Lepidi, S.; Cognolato, D.; Dall’Antonia, A.; Stramanà, R.; Deriu, G.P.; Grego, F. Open repair versus endovascular treatment for asymptomatic popliteal artery aneurysm: Results of a prospective randomized study. Journal of vascular surgery 2005, 42, 185–193, doi:https://doi.org/10.1016/j.jvs.2005.04.049.
14. Moreira, C.C.; Leung, A.D.; Farber, A.; Rybin, D.; Doros, G.; Siracuse, J.J.; Kalish, J.; Eslami, M.H. Alternative conduit for infrageniculate bypass in patients with critical limb ischemia. Journal of vascular surgery 2016, 64, 131–139.e131, doi:https://doi.org/10.1016/j.jvs.2016.01.042.
15. Avgerinos, E.D.; Sachdev, U.; Naddaf, A.; Doucet, D.R.; Mohapatra, A.; Leers, S.A.; Chaer, R.A.; Makaroun, M.S. Autologous alternative veins may not provide better outcomes than prosthetic conduits for below-knee bypass when great saphenous vein is unavailable. Journal of vascular surgery 2015, 62, 385–391, doi:https://doi.org/10.1016/j.jvs.2015.03.025.
16. Brendel, J.M.; Mangold, T.; Pfändler, M.; Stenzl, B.; Andic, M.; Mück, J.; Schmehl, J.; Krumm, P.; Artzner, C.; Grözinger, G.; et al. Viabahn endoprosthesis for femoropopliteal aneurysm repair: safety, success rates, and long-term patency. CVIR Endovascular 2024, 7, 53, doi:10.1186/s42155-024-00465-3.
17. Stone, P.A.; Armstrong, P.A.; Bandyk, D.F.; Keeling, W.B.; Flaherty, S.K.; Shames, M.L.; Johnson, B.L.; Back, M.R. The value of duplex surveillance after open and endovascular popliteal aneurysm repair. Journal of vascular surgery 2005, 41, 936–941, doi:10.1016/j.jvs.2005.03.021.
18. Committee, E.G.; Document, R.; Wanhainen, A.; Van Herzeele, I.; Bastos Goncalves, F.; Bellmunt Montoya, S.; Berard, X.; Boyle, J.R.; D’Oria, M.; Prendes, C.F.; et al. Editor's Choice -- European Society for Vascular Surgery (ESVS) 2024 Clinical Practice Guidelines on the Management of Abdominal Aorto-Iliac Artery Aneurysms☆. European Journal of Vascular and Endovascular Surgery 2024, 67, 192–331, doi:10.1016/j.ejvs.2023.11.002.
19. Hofmann, A.G.; Mlekusch, I.; Wickenhauser, G.; Assadian, A.; Taher, F. Clinical Applications of B-Flow Ultrasound: A Scoping Review of the Literature. Diagnostics (Basel) 2023, 13, doi:10.3390/diagnostics13030397.
20. Hofmann, A.G.; Klosz, F.R.; Mlekusch, I.; Wickenhauser, G.; Walter, C.; Assadian, A.; Taher, F. Endoleak Detection after Endovascular Aortic Repair via Coded-Excitation Ultrasound-A Feasibility Study. J Clin Med 2023, 12, doi:10.3390/jcm12113775.
21. Hofmann, A.; Mlekusch, I.; Wickenhauser, G.; Walter, C.; Falkensammer, J.; Assadian, A.; Taher, F. Ultrasound Coded-Excitation Imaging for Endoleak Detection After Complex Endovascular Aortic Repair. J Ultrasound Med 2024, 43, 429–437, doi:10.1002/jum.16374.
